NCVM-5200 V-Grooving Machine

The NCVM-5200 grooving machine is a high-performance tool designed for precision metalworking, capable of handling materials up to 5200mm in length. It combines speed, accuracy, and reliability, making it ideal for demanding industries like aerospace, automotive, and construction.

Key Features

  • High stability
  • fully automatic processing
  • high efficiency
  • low noise and environmental protection

Detailed Description

The NCVM-5200 grooving machine is an advanced, high-performance tool designed for precision metalworking in industries such as aerospace, automotive, shipbuilding, and construction. With its ability to handle materials up to 5200mm in length and 1600mm in width, it offers a versatile solution for both large-scale and intricate grooving operations. The machine’s precision, speed, and reliability make it ideal for high-demand production environments.

Key Features and Advantages:

1. High-Speed Manufacturing: The NCVM-5200 delivers exceptional processing speed, with a cutting speed of up to 120m/min on the X-axis and a matching return speed. The Y-axis and Z-axis feeding systems operate at 0-20m/min, ensuring efficient handling of both large and small workpieces, while maintaining high accuracy.

2. Precision Grooving: Equipped with a ±0.1mm resolution on both the Y and Z axes, the NCVM-5200 guarantees precise grooving across a wide range of materials. The Y-axis has a maximum feeding distance of 1250mm, while the Z-axis allows for 30mm of vertical movement, providing flexibility for detailed work.

3. Robust Hydraulic System: The NCVM-5200 features a powerful 2.2kW hydraulic system with a fluid capacity of 8L and a pressure rating of 10mpa. This system ensures stable clamping during operation, preventing any movement or vibration of the workpiece, thus maintaining accuracy during high-speed cutting processes.
